R spider
BL800
4
Bright‚ many effects and looks
Unique 'tungsten' LED effect
Multi-point surface light and back light with pixel control
High output‚ low energy consumption‚ good heat dissipation‚ long life
Outstanding strobe effects
Smooth dimming from 0-100%
Hidden‚ accessories-free interlocking system for combining units
Unique 'tungsten' LED effect
Multi-point surface light and back light with pixel control
High output‚ low energy consumption‚ good heat dissipation‚ long life
Outstanding strobe effects
Smooth dimming from 0-100%
Hidden‚ accessories-free interlocking system for combining units
Quantity
IP67 Pixel Blinder Light
The BL800 is a professional IP67 Pixel Blinder Light designed for concerts, festivals, touring productions and outdoor
stage events. Featuring 10 × 50W R+A+WW LEDs with individual pixel control, it delivers dynamic audience effects,
creative lighting looks and realistic tungsten emulation. Its rugged IP67 construction ensures reliable performance
for demanding outdoor productions and rental applications.
Technical Specifications
Light source
Light source: 10 x 50W LED (R+A+WW)
Outer ring LED: 8x 56 x 0.5W LED (RGB)
LED expected service life: 20‚000 hours
Angle: 15°/26°/36°optional
Control and Program
4 touch buttons
Control panel: LCD display screen
Control mode: DMX512‚RDM
DMX channel mode: 4
Control channel: 4/15/23/47/200CH optional
Software upgrade: Update software via DMX512 connection
Electrical and Connector
Adaptive power source
Input voltage range: 100-240V~ 50/60Hz
Rated power: 650 W
Power source input/output: Power connector input/output
Signal input/output: three-pin XLR socket
Light source: 10 x 50W LED (R+A+WW)
Outer ring LED: 8x 56 x 0.5W LED (RGB)
LED expected service life: 20‚000 hours
Angle: 15°/26°/36°optional
Control and Program
4 touch buttons
Control panel: LCD display screen
Control mode: DMX512‚RDM
DMX channel mode: 4
Control channel: 4/15/23/47/200CH optional
Software upgrade: Update software via DMX512 connection
Electrical and Connector
Adaptive power source
Input voltage range: 100-240V~ 50/60Hz
Rated power: 650 W
Power source input/output: Power connector input/output
Signal input/output: three-pin XLR socket
N.W.:13.2KG
Material
All cast aluminum
Waterproof level
IP67
Material
All cast aluminum
Waterproof level
IP67
Applications
The BL800 combines high-output LEDs, pixel control and tungsten-style dimming effects to create powerful visual impact for live entertainment. Individual pixel control allows lighting designers to build dynamic chases, color effects and audience lighting moments. With IP67 protection and a hidden interlocking system, the fixture is suitable for outdoor concerts, festivals, touring shows and large-scale stage productions. OEM and ODM customization services are available for professional lighting brands and distributors.
